Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-14
6. Finish Gathering Information
6. Finish Gathering Information
At this stage, you treat and configure each enclosure separately. Before you configure
an enclosure into a block, you must supply its IP information. IP information for an
enclosure is recorded on different worksheets, depending on whether the enclosure
came directly from the factory or from a donor system.
Make a copy of Worksheet 7 and keep it accessible. You will use it later when you
configure the enclosures into a block.
If Enclosure Comes From the Factory
If the enclosure was shipped directly from the factory, it contains default IP addresses.
These addresses are listed in Table 6-3 and preprinted on Worksheet 7.
If Enclosure Comes From a Donor System
If the enclosure is coming from a donor system, you already recorded the slot 50 and
slot 55 IP addresses on Worksheet 2.n of the donor system packet during Step
2.1 Record Basic Information on page 4-4.
Contact your network administrator to identify the subnet mask and gateway route
IP addresses for the donor system.
On Worksheet 7 of the donor system packet, record these values and the information
from Worksheet 1.
Note. IP addresses for the ServerNet switch boards of the IOAM enclosures are dynamically
assigned by a DHCP server or software that performs the same function.
Table 6-3. Default MSP IP Addresses
Item Value
Slot 50 192.231.36.2
Slot 55 192.231.36.3
Subnet Mask 255.255.255.0
Gateway Route 192.231.36.9
