Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-15
7. Connect a System Console to the Enclosure
7. Connect a System Console to the Enclosure
Both the system console that you will connect to the enclosure and the enclosure itself
must be offline (and therefore isolated). Until you configure the enclosure into a block,
it cannot share a network with the target system.
Using the procedure Move the System Console on page A-8, connect to the enclosure
the system console selected in Step 5.1 Choose System Console to Use on page 6-11.
Caution. Before you perform this step, ensure that:
•
The enclosure is powered off.
•
The system console that you will connect to the enclosure is running a version of the OSM
or TSM client software that is compatible with your RVU and TSM server software.
To determine the product version of OSM or TSM client software on the system console,
see Determine the Product Version of the TSM Client Software
on page A-7.
For instructions about how to upgrade the OSM or TSM client software on the system
console, see the NonStop System Console Installer Guide for the instructions for the
version you plan to install.
Note. To migrate a system console to the Microsoft Windows 2000 Professional operating
system, see NonStop System Console Guide for Migrating to Microsoft Windows XP
Professional. For additional information, see Hotstuff HS02701A.
