OSI/AS SCF Commands
OSI/AS SCF Reference Manual—424121-001
2-121
CHECK ENTRY Command
Applications Checked
shows the names of the local and remote application entry names.
INFO ENTRY Displays
the first section of this display shows all the INFO ENTRY displays for the local
and remote application entry names:
INFO ENTRY #APPL
INFO ENTRY #TSEL (detailed)
INFO ENTRY #NSAP (detailed)
INFO ENTRY #SNPA (detailed)
Server Detail
this section provides the detail of the servers for the local and remote application
entry names that would be used in the connection.
L3 Service:
*ESISEnable........ ON *ESISChecksum...... OFF
*ESISESConfTime.... 0:01:00.00 *ESISESGroupMACAddr 09002B000004
*ESISHoldTime...... 0:01:00.00 *ESISISGroupMACAddr 09002B000005
*ESISNotifyIS...... OFF *ESISQueryRetry.... 3
*ESISQueryTime..... 0:00:01.00
*IPChecksum........ OFF *IPDiscardAddrThld. 0
*IPDiscardCongThld. 0 *IPDiscardGenThld.. 0
*IPDiscardLifeThld. 0 *IPDiscardReasmThld 0
*IPDiscardUnsupThld 0 *IPLifeTime........ 0:00:15.00
*IPNullLayer....... OFF *IPX25SNDCF........ OFF
*IPX25SNDCF1980Addr ON
*X25AcceptChg...... OFF *X25BCUG...........
*X25CUG............ *X25CUGType........
*X25DestAddr....... *X25DisconnectDelay 0:00:05.00
*X25NConMultiplex.. 512
*X25Negotiate......
*X25Port........... 0 *X25PriCall........ OFF
*X25PVC............ *X25RemoteNet......
*X25ReverseChg..... OFF
X25RPOA ..........
*X25Thruput........ *X25TransitDelay...
L3 Profile: none specified
Configuration verified.
Note. If any verification errors are discovered while simulating the connection, warning
messages will appear interspersed with the fields of the display.
This message may be displayed: “Note: Lack of a remote SNPA entry will not cause validation
failure”
This message is displayed if the configuration specifies a remote SNPA value in the NSAP
entry and the associated remote SNPA entry does not exist in the MIB. This is not an error
condition and the configuration would be considered verified (assuming there are no other
errors).
