OSI/AS SCF Commands
OSI/AS SCF Reference Manual—424121-001
2-129
CHECK ENTRY Command
INFO ENTRY Displays
the first section of this display shows all the INFO ENTRY displays:
INFO ENTRY #APPL
INFO ENTRY #TSEL (detailed)
INFO ENTRY #NSAP (detailed)
INFO ENTRY #SNPA (detailed)
Server Detail
this section provides the detail of the servers that would be used in the connection.
TAPS server detail
shows detailed information about the TAPS server that will be used if this
#APPL entry is used.
Source
shows from which MIB entry (#APPL or #TSEL and called or calling) the
TAPS server was selected.
*X25AcceptChg...... OFF *X25BCUG...........
*X25CUG............ *X25CUGType........
*X25DestAddr....... *X25DisconnectDelay 0:00:05.00
*X25NConMultiplex.. 512
*X25Negotiate......
*X25Port........... 0 *X25PriCall........ OFF
*X25PVC............ *X25RemoteNet......
*X25ReverseChg..... OFF
X25RPOA ..........
*X25Thruput........ *X25TransitDelay...
L3 Profile: $TMGR.#L3.L3PROFIL
Source: $TMGR.#APPL.CALLED
*IPNullLayer...... OFF *IPX25SNDCF....... OFF
*X25AcceptChg..... OFF *X25BCUG..........
*X25CUG........... *X25CUGType.......
*X25DestAddr...... 123456789012345
*X25Negotiate.....
*X25Port.......... 0 *X25PriCall....... OFF
*X25PVC........... *X25RemoteNet.....
*X25ReverseChg.... OFF
X25RPOA .........
*X25Thruput....... *X25TransitDelay..
Configuration verified.
Note. If any verification errors are discovered while simulating the connection, warning
messages will appear intermixed with the fields of the display. For example, “OSI/AS E-00017
Object $MGR.#TSEL.F004 Not Found” would appear in the place where the #TSEL
information is displayed. The final line of the display would then read “Configuration contained
errors!”
