OSI/AS SCF Commands
OSI/AS SCF Reference Manual—424121-001
2-151
INFO PROFILE #L3 Command
INFO PROFILE #L3 Command
The format of the display for the INFO PROFILE #L3 command without the DETAIL
option is
Name
shows the name of the profile object.
IPNullLayer
shows whether the null (inactive subset) of the internet protocol in the Network
Layer is enabled or disabled.
IPX25SNDCF
shows whether the subnetwork dependent convergence function is used.
The format of the display for the INFO PROFILE #L3 command with the DETAIL
option is
IPNullLayer
shows whether the null (inactive subset) of the internet protocol in the Network
Layer is enabled or disabled.
IPX25SNDCF
shows whether the subnetwork dependent convergence function is used.
X25AcceptChg
shows whether incoming collect calls are accepted.
OSIAS Info PROFILE
Name *IPNullLayer *IPX25SNDCF
$OSIM.#L3.PROF1 OFF OFF
OSIAS Detailed Info PROFILE \MARS.$OSIM.#L3.PROF1
*IPNullLayer....... OFF *IPX25SNDCF........ OFF
*X25AcceptChg...... OFF *X25BCUG........... 0
*X25CUG............ *X25CUGType........ BASIC
*X25DestAddr: 00149611234
*X25Negotiate...... L3WINDOW PKTSIZE THRUPUT
*X25Port........... 10 *X25PriCall........ OFF
*X25PVC............ 4 *X25RemoteNet...... TELENET
*X25ReverseChg..... OFF
*X25RPOA........... ( 3109,2460,4566 )
*X25Thruput...... ( 4,4 ) *X25TransitDelay... 600
