OSI/AS SCF Commands
OSI/AS SCF Reference Manual—424121-001
2-153
INFO PROFILE #L4 Command
INFO PROFILE #L4 Command
The format of the display for the INFO PROFILE #L4 command without the DETAIL
option is
Name
shows the name of the profile object.
Class
shows the preferred transport protocol class value.
TPDUSize
shows the maximum length of a TPDU.
Checksum
shows whether checksum fields are added to TPDUs.
NetType
shows the quality of the network services.
Expedited
shows whether the transport expedited data transfer service is supported.
The format of the display for the INFO PROFILE #L4 command with the DETAIL
option is
AltClass
shows the alternative transport protocol class value.
OSIAS Info PROFILE
Name *Class *TPDUSize *Checksum *NetType *Expedited
$OSIM.#L4.P1 2 1024 OFF A OFF
OSIAS Detailed Info PROFILE \MARS.$TMGR.#L4.L4000001
*Altclass......... 0 *Checksum......... ON
*Class............ *Connecttimeout.... 0:02:00.00
*Disconntimeout... 0:02:00.00 *Expedited........ OFF
*Extendedformat... OFF *Inactivetimeout.. 0:00:30.00
*L4window......... 4 *Maxrexmit........ 3
*Multiplex........ OFF *Nettype.......... A
*Recvsecurity..... *Reftimeout........ 0:00:30.00
*Rexmittimeout.... 0:00:10.00 *Sendsecurity.....
*Tconpri.......... 0 *TPDUsize......... 512
*TTRtimeout....... 0:01:30.00 *TWRtimeout....... 0:02:00.00
*Windowtimeout.. 0:00:10.00
