OSI/AS SCF Commands
OSI/AS SCF Reference Manual—424121-001
2-161
INFO SERVICE #L4 Command
AltClass
shows the alternative transport protocol class value.
Checksum
shows whether checksum fields are added to TPDUs.
CheckTSEL
shows whether or not the responding transport address in the Connect Confirm
TPDU (CC-TPDU) is checked.
Class
shows the preferred transport protocol class value.
ConnectTimeout
shows the amount of time to wait for responses to CR-TPDUs.
DisconnTimeout
shows the amount of time to wait for responses to DR-TPDUs.
Expedited
shows whether the transport expedited data transfer service is supported.
ExtendedFormat
shows whether the credit and sequence numbers of TPDUs should be in the
extended format (ON) or normal format (OFF).
OSIAS Detailed Info SERVICE \MARS.$OSIM.#L4
*AltClass................ 0 *Checksum................ OFF
*CheckTSEL............... ON *Class................... 2
*ConnectTimeout.......... 0:00:60.00 *DisconnTimeout.......... 0:02:00.00
*Expedited............... OFF *ExtendedFormat.......... OFF
*InactiveTimeout......... 0:00:30.00 *InboundCRConfErrThld.... 0
*InboundCRCongestionThld. 0 *InboundCRProtoErrThld... 0
*InboundTPDUProtoErrThld. 0 *InboundTPDUXsumErrThld.. 0
*L4TimeoutThld........... 0 *L4Window................ 8
*MaxRexmit............... 3 *Multiplex............... OFF
*NetType................. A *OutboundCRConfErrThld... 0
*OutboundCRErrThld....... 0 *OutboundTPDUProtoErrThld 0
*PassiveMUX.............. OFF
*RecvSecurity............ RECVSEC
*RefTimeout.............. 0:00:30.00 *RexmitTimeout........... 0:00:12.00
*SendSecurity............ SENDSEC
*TConPri................. 0 *TPDUSize................ 512
*TTRTimeout.............. 0:00:12.00 *TWRTimeout.............. 0:01:00.00
*WindowTimeout........... 0:00:12.00
