OSI/AS SCF Commands
OSI/AS SCF Reference Manual—424121-001
2-197
STATS SERVICE #ACSE Command
CPA PPDU Received
shows the number of times the Presentation layer received a Connect Presentation
Accept (CPA) PPDU. This counter wraps around upon overflow.
STATS SERVICE #ACSE Command
The format of the display for the STATS SERVICE #ACSE command is
Reset Time
shows the date and time the statistics counters were last reset.
Sample Time
shows the date and time the statistics were gathered.
AARE (Rejected) APDUs Received
shows the number of times the ACSE service received an AARE-APDU with a
result field of “rejected permanent (1)” or “rejected temporary (2),” regardless of
source. This counter wraps around upon overflow.
AARE (Rejected) APDUs Sent
shows the number of times the ACSE service sent or attempted to send an AARE-
APDU with a result field of “rejected permanent (1)” or “rejected temporary (2),”
regardless of source. This counter wraps around upon overflow.
Value 0 through 65535
OSIAS Stats SERVICE \MARS.$TAS0.#ACSE
Reset Time.... 20 Jun 1991, 18:23:19.300
Sample Time... 20 Jun 1991, 18:27:18.749
Received Threshold Sent Threshold
AARE (Rejected) APDUs......... 0 -- 0 --
AARE (Rejected,Prov) APDUs.... 0 0 0 0
ABRT (Provider) APDUs......... 0 5 0 0
ACPM A-PABind's............... -- -- 0 0
ACPM A-ASCcnf's(Rej.Perm,Prov) -- -- 0 0
AARQ APDUs.................... 0 1
AARE (Accepted) APDUs......... 1 0
RLRQ APDUs.................... 0 0
RLRE (Accepted) APDUs......... 0 0
RLRE (Rejected) APDUs......... 0 0
Value 0 through 65535
Value 0 through 65535
