OSI/AS Trace Facility
OSI/AS SCF Reference Manual—424121-001
3-35
ASN.1—ACSE Encode
Error Subcode
shows either a null value or a description of the erroneous parameter.
Protocol^Version
shows the version number of the presentation layer protocol as specified in either
the AARQ-APDU or the AARE-APDU.
PCID
shows the presentation context identifier.
PDU Addr
shows the address of the protocol data unit.
PDU Len
shows the length of the protocol data unit.
ASN.1—ACSE Encode
This trace record shows the result of encoding an ACSE PDU. A zero (0) or null error
code and error subcode means that no error was detected.
Subtype
ASN.1 ACSE Encode
Su Name
shows the name of the associated TAPS subdevice.
Error
shows whether a null value or the zaps-err-parameter.
Error Subcode
shows either a null value or a description of the erroneous parameter.
Protocol^Version
shows the version number of the presentation layer as specified in either the AARQ-
APDU or the AARE-APDU.
08:20:07.760 >000.060 #138 TAPS ASN.1
ASN.1 ACSE Encode Su Name #ZMF0020
Error = ZAPS^Err^Ok(0), Error Subcode = (0).
Protocol^Version %H8000 PCID 00031
PDU Addr %H80000000 PDU Len 00000
