OSI/AS Trace Facility
OSI/AS SCF Reference Manual—424121-001
3-51
ACSE—ACSE Error Report
MCB Addr
an internal field that shows the address of the control block that contains the DCB
address.
MCB Tag
an internal field that is used to match requests with corresponding replies.
DCB Addr
an internal field that shows the address of the Data Control Block that contains the
Compaq internal request or response primitive structure and header information.
Request Len
an internal field that shows the length of the primitive structure.
Request code
is one of the following requests that originated from the APS user:
<..Request Detail..>
shows the parameters associated with an APS procedure call. See the OSI/AS
Programming Manual for parameter descriptions.
ACSE—ACSE Error Report
The record shows a change to either Status Code, Error, or Error Subcode recorded
during ACSE processing.
Value Meaning
-32767 Attach Req
00001 Connect Req
00002 Connect Rsp
00028 Release Req
00029 Release Rsp
00030 User Abort Req
Note. Note that ACSE sometimes generates a User Abort Req (-00030) in error
situations, typically if a protocol error is detected in an incoming event.
08:20:09.610 >000.020 #1141 TAPS ACSE
ACSE Error Report Su Name #ZMF0021
Status Code = ZAPS^Val^Status^Discard (7)
Error = ZAPS^Err^Operator^Abort(-114), Error Subcode = (0).
