OSI/AS Trace Facility
OSI/AS SCF Reference Manual—424121-001
3-52
ACSE SM—ACSE State Machine
Subtype
ACSE Error Report
SU Name
shows the name by which APS knows this connection.
Status Code
show the status code returned to the APS procedure. See the OSI/AS Programming
Manual for descriptions of possible values.
Error
shows the error returned to the APS procedure. See the OSI/AS Programming
Manual for descriptions of possible values.
Error Subcode
shows the error subcode returned to the APS procedure. See the OSI/AS
Programming Manual for descriptions of possible values.
ACSE SM—ACSE State Machine
This trace record shows transitions made through the ACSE state machine.
Format without statetables loaded:
Format with statetables loaded:
Subtype
ACSE State Machine
SU Name
shows the name by which APS knows this connection.
Request ID
an internal field that shows the address of the user request buffer. When dealing with
an incoming event, this value is often null (%H0000000).
08:20:07.860 >000.010 #125 TAPS ACSE SM
ACSE SM Su Name #ZMF0021 Request ID %H000A5FB2
State 00001 Event 00005 Action 00006
08:20:09.490 >000.000 #1054 TAPS ACSE SM
ACSE SM Su Name #ZMF0021 Request ID %H000A6A1E
State 00005 -- ASSOCIATED^STA5
Event 00008 -- A^RLSREQ
Action 00016 -- PROCESS^A^RLSREQ
