OSI/AS Trace Facility
OSI/AS SCF Reference Manual—424121-001
3-65
L6 PROV—L5 Event
Subtype
L5 Event
SU Name
shows the name by which APS knows this connection.
MCB Addr
an internal field that shows the address of the TAPS internal Message Control
Block. The data associated with the event is in the DCB pointed to by the MCB.
DCB Addr
an internal field that shows the address of the buffer holding the event data.
DCB Len
an internal field that shows the length of the control block containing the event data.
Event code
shows which event (a primitive or error) has been received. The possible values are
08:20:08.080 >000.000 #225 TAPS L6 PROV
L5 Event Su Name #ZMF0020
MCB Addr %H000A5F84 DCB Addr %H001C6312 DCB Len 00088
Event Code 00022 (Activity Interrupt Ind)
Reason = receiving ability jeopardized
user^data.hdr.znum^elements = 1
user^data.element[0].hdr.zlen = 14 .ztype = 1 .zpcid = 0
Value Meaning Value Meaning
00001 Connect Ind 00017 Resynchronize Cnf
00002 Connect Cnf 00019 User Exception Report Ind
00003 Data Ind 00020 Activity Start Ind
00005 Typed Data Ind 00021 Activity Resume Ind
00006 Capability Data Ind 00022 Activity Interrupt Ind
00007 Capability Data Cnf 00023 Activity Interrupt Cnf
00008 Token Give Ind 00024 Activity Discard Ind
00009 Token Please Ind 00025 Activity Discard Cnf
00010 Control Give Ind 00026 Activity End Ind
00012 Sync Minor Ind (Ack Requested) 00027 Activity End Cnf
00013 Sync Minor Cnf 00028 Release Ind
