OSI/AS Trace Facility
OSI/AS SCF Reference Manual—424121-001
3-73
L6—L6 Error Report
Subtype
L6 Provider Reply.
SU Name
shows the name by which APS knows this connection.
Reply Addr
an internal field that shows the address of the buffer controlling the original user
request.
Request Tag
an internal field that shows the Request Tag associated with the request by APS.
Status Code
shows the status code returned to the APS procedure. See the OSI/AS Programming
Manual for descriptions of possible values.
Error
shows the error returned to the APS procedure. See the OSI/AS Programming
Manual for descriptions of possible values.
Error Subcode
shows the subcode returned to the APS procedure. See the OSI/AS Programming
Manual for descriptions of possible values.
L6—L6 Error Report
The record shows a change to either Status Code, Error, or Error Subcode
recorded during L6 processing.
Subtype
L6 Error Report
08:20:07.190 >000.010 #65 TAPS L6 PROV
L6 Prov Reply Su Name #ZMF0020
Reply Addr %H000A5DE6 Request Tag %H000116C4
Status Code = ZAPS^Val^Status^Ok (0)
Error = ZAPS^Err^Ok(0), Error Subcode = (0).
01/09/91 04:36:56.484572 >000.317884 #173 TAPS L6
L6 Error Report Su Name #Z000016
Status Code = ZAPS^Val^Status^Discard (7)
Error = ZAPS^Err^Operator^Abort(-114), Error Subcode = (0).
