OSI/AS Trace Facility
OSI/AS SCF Reference Manual—424121-001
3-74
L6 SM—L6 State Machine
SU Name
shows the name by which APS knows this connection.
Status Code
shows the status code returned to the APS procedure. See the OSI/AS Programming
Manual for descriptions of possible values.
Error
shows the error returned to the APS procedure. See the OSI/AS Programming
Manual for descriptions of possible values.
Error Subcode
shows the error subcode returned to the APS procedure. See the OSI/AS
Programming Manual for descriptions of possible values.
L6 SM—L6 State Machine
The record shows transitions made through the L6 state machine. There are two display
formats: one contains information for error-free state machines, the other contains
information for recovery after error detection and the recovered state.
Format without statetables loaded:
Format with statetables loaded:
Subtype
L6 Protocol State Machine
SU Name
shows the name by which APS knows this connection.
08:20:07.700 >000.000 #105 TAPS L6 SM
L6 Proto SM Su Name #ZMF0020 Request ID %H000A5E9E
State 00000 Event 00059 Action 00004
08:20:10.430 >000.000 #1199 TAPS L6 SM
L6 Proto SM Su Name #ZMF0023 Request ID %H000A6AD6
State 00000 -- L6^IDLE^NO^PC^STAI0
Event 00014 -- L6^P^CONREQ
Action 00001 -- DO^CP^04^05^02^20
01/09/91 04:36:56.165477 >000.000000 #159 TAPS L6 SM
L6 Proto SM Su Name #Z000016 Request ID %H000A6B32
State 00007 -- L6^PSEUDO^STATE^RECOVERY
Event 00070 -- L6^RECOVER
Action 00098 -- RECOVER^PREVIOUS^STATE
Recovered State 00000 -- L6^IDLE^NO^PC^STAI0
