OSI/AS Trace Facility
OSI/AS SCF Reference Manual—424121-001
3-98
L5 PROV—L5 Send TSDU Continuation
Send Length
shows the number of bytes in the TSDU.
<..TSDU Data..>
shows the contents of the TSDU. Each TSDU has a different format. Details of
SPDU contents can be found in ISO 8327.
L5 PROV—L5 Send TSDU Continuation
This trace record is another example of an L5 PROV—L5 Send TSDU trace record. It
shows how a TSDU might look as a result of an L5 Multi Mid Request.
Subtype
L5 Send TSDU
SU Name
shows the name by which APS knows this connection.
Session ID
an internal field that shows a sequence number that is assigned to the connection by
this TAPS process.
Request ID
an internal field that shows the address of the buffer that controls the user request
that caused this TSDU to be written.
Send length
shows the number of bytes in this fragment of the TDSU.
User Information
shows unformatted user data.
Note. Session breaks TSDUs into fragments when writing to transport. The size of a fragment
depends on MAXCONNECTIONS but will never be less than 1000 bytes. Lower layer
processes may further fragment the original TSDU based on configuration or SYSGEN
parameters.
02/06/91 12:17:14.099547 >000.000208 #188 TAPS L5 PROV
L5 Send TSDU Su Name #ZMF000B Session ID 12
Request ID %H000AD702 MCW %H0001 Send Length 00003 (Continuation)
User Information: (1+) 82
(1+) .
