OSI/AS Trace Facility
OSI/AS SCF Reference Manual—424121-001
3-99
L5 PROV—L5 Start Timer
L5 PROV—L5 Start Timer
This trace record indicates that the session disconnect timer has been started. The
disconnect timer is started in accordance with ISO 8327 after a DN-SPDU
(release/response) is sent to the remote session service provider. If the remote does not
respond and disconnect transport within the given time, it is the local service provider's
responsibility to disconnect. Issuing the final transport disconnect depends on timing,
load and other factors.
Subtype
L5 Start Timer
SU Name
shows the name by which APS knows this connection.
Session ID
an internal field that shows a sequence number assigned to the connection by this
TAPS process.
Timer Element
an internal field that shows the value returned by signaltimeout.
Tag
an internal field that is returned by a Guardian procedure to identify when the start
timer expired.
Ticks
shows, in hundredths of a second, the lifetime of the start timer.
L5 PROV—L5 Cancel Timer
This trace record indicates that the disconnect timer is being cancelled. The record will
be seen when the expected disconnect is received by the local session service provider
or as part of a local disconnect operation.
08:20:17.070 >007.480 #3209 TAPS L5 PROV
L5 Start Timer Su Name #ZMF0027 Session ID 70
Timer Element 10 Tag %H0012DE16 Ticks 300
08:20:17.120 >000.050 #3235 TAPS L5 PROV
L5 Cancel Timer Su Name #ZMF0027 Session ID 0
Timer Element 10
