OSI/AS Trace Facility
OSI/AS SCF Reference Manual—424121-001
3-101
L5—L5 State Machine
Subtype
L5 Error Report
SU Name
shows the name by which APS knows this connection.
Status Code
shows the status code returned to the APS procedure. See the OSI/AS Programming
Manual for descriptions of possible values.
Error
shows the error returned to the APS procedure. See the OSI/AS Programming
Manual for descriptions of possible values.
Error Subcode
shows the error subcode returned to the APS procedure. See the OSI/AS
Programming Manual for descriptions of possible values. The error -114 indicates
that TAPS has received a close system message for the subdevice.
L5—L5 State Machine
This trace record shows transitions made through the L5 state machine.
Format without statetables loaded:
Format with statetables loaded:
Subtype
L5 State Machine
08:20:09.610 >000.000 #1139 TAPS L5
L5 Error Report Su Name #ZMF0021
Status Code = ZAPS^Val^Status^Discard (7)
Error = ZAPS^Err^Operator^Abort(-114), Error Subcode = (0).
08:20:07.960 >000.000 #180 TAPS L5 SM
L5 SM Su Name #ZMF0020 Session ID 84 Request ID %H80000000
State 00029 Event 00069 Action 00255
08:20:08.380 >000.000 #378 TAPS L5 SM
L5 SM Su Name #ZMF0021 Session ID 64 Request ID %H000A6264
State 00029 -- S^STATE^AWAIT^CDA^STA21
Event 00041 -- E^REQ^ACTDISC
Action 00236 -- CHECK^ACTSTART^STA713
