OSI/AS SCF Commands
OSI/AS SCF Reference Manual—424121-001
2-43
ADD PROFILE #L4 Command
ADD PROFILE #L4 Command
An attribute-spec for the ADD PROFILE #L4 command is one of the following
attribute name and value combinations:
ALTCLASS
specifies the protocol class to be used as an alternative to the preferred protocol
class. See Considerations for the ADD Command on page 2-50 for a discussion of
the relationship between the ALTCLASS, CLASS, MULTIPLEX, and NETTYPE
attributes.
CHECKSUM
specifies whether checksum fields are added to TPDUs. This attribute is valid only
when the transport protocol class is 4.
[ ALTCLASS { 0 | 1 | 2 | 3 | 4 } ]
[ CHECKSUM { ON | OFF } ]
[ CLASS { 0 | 1 | 2 | 3 | 4 } ]
[ CONNECTTIMEOUT time ]
[ DISCONNTIMEOUT time ]
[ EXPEDITED { ON | OFF } ]
[ EXTENDEDFORMAT { ON | OFF } ]
[ INACTIVETIMEOUT time ]
[ L4WINDOW integer ]
[ MAXREXMIT integer ]
[ MULTIPLEX { ON | OFF } ]
[ NETTYPE { A | B | C } ]
[ RECVSECURITY “text” ]
[ REFTIMEOUT time ]
[ REXMITTIMEOUT time ]
[ SENDSECURITY “text” ]
[ TCONPRI integer ]
[ TPDUSIZE
{ 128 | 256 | 512 | 1024 | 2048 | 4096 | 8192 } ]
[ TTRTIMEOUT time ]
[ TWRTIMEOUT time ]
[ WINDOWTIMEOUT time ]
Value: 0 | 1 | 2 | 3 | 4
Default: Defaults to the value of the ALTCLASS attribute in the
ALTER #L4 SERVICE command.
Value: ON | OFF
Default: Defaults to the value of the CHECKSUM attribute in the
ALTER #L4 SERVICE command.
