For information on how to replace an individual IOAM Fan, see the CSSI web site.
Location in OSM Tree: System > Group > IOAM Enclosure > IOAM > Fan
Example: Fan (13.2.16)
Attributes
Physical
LED State
Indicates whether or not the fans amber LED is lit. This state is determined by the Set
LED State action.
Value: On or Off
Logical
Device State
The state of the component as known to the operating system on the server. Values
Actions
Set LED State
Turns on or off the amber LED located on the fan. The current state is indicated by the LED State
attribute.
FC-AL I/O Module
Attributes
Actions
Subcomponent of a Disk Drive Enclosure.
There are two FC-AL I/O Modules in each enclosure. These modules are the interface between the
drive enclosure elements and the host controller. They route data to and from the drives using loop A
and loop B.
Location in OSM Tree: System > Group > Daisy Chained Disk Drive Enclosure > Disk Drive
Enclosure > FC-AL I/O Module
Example: FC-AL I/O Module (111.211.1.93)
Attributes
FC-AL I/O Module
