Displays the procedure for replacing the FC-AL I/O module.
FCSA
Attributes
Actions
Removing and Installing a Fibre Channel ServerNet Adapter
Fibre Channel ServerNet adapter. The FCSA object always displays two FCSA FSACs, regardless of
whether they are both physically present. At least one must be present to perform FCSA firmware
updates. The FCSA FSAC attributes Node Name and Port Name indicate the presence of FCSA
FSACs and attached disks. Unlike many other adapters, the ports on the FCSA are numbered from
top down when viewing the FCSA installed in a rack. Thus, FCSA FSAC 1 is attached to the upper
port (port 1), FCSA FSAC 2 is attached to the lower port (port 2).
Note: If a ServerNet switch board is not present, FCSAs will not appear in OSM.
OSM will not display FCSA attribute information until an associated disk process is configured and
started. For more information, see the Fibre Channel ServerNet Adapter Installation and Support
Guide.
Location in OSM Tree: System > Group > IOAM Enclosure > IOAM > FCSA
Example: FCSA (13.3.1)
Attributes
FCSA
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Physical
Hardware Revision
A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.
Part Number
The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.
Track ID
A unique serial number that identifies the component. Track IDs are used for
tracking components.
Flash Firmware
Information about the version of the operational firmware located in the Flash memory of the FCSA.
This firmware is not used in NonStop S-series systems as they do not support system load through
the FCSA.
