Configured Type
The configuration type of this resource.
Values: CCSA, E4SA, FESA, G4SA, GESA, TRSA, Unknown
Device State
The state of the component as known to the operating system on the server.
Values
Actions
Abort
Terminates operation of the G4SA and the associated Ethernet ServerNet addressable controller
(SAC). When the Abort action finishes, the G4SA and the SAC are in the Stopped state.
Add
This action is displayed in OSM only when a G4SA is first inserted and not yet configured.
Performing this action ensures that the Configured Type is set to G4SA.
Delete
Deconfigures the G4SA, removing the associated G4SA SAC and PIF objects. This action can only
be performed after you delete the LIF associated with each G4SA PIF.
Power Off
Physically powers off the G4SA.
Reset
Places the G4SA in a state from which it can be started.
Start
Starts the G4SA and the associated G4SA SAC. The G4SA and the SAC must be in the Stopped state
before you perform this action.
Stop
Rather than automatically stopping the G4SA (as the Abort action does), this action first warns you if
the G4SA is currently in use (and stops it only after you confirm).
G4SA PIF
Attributes
Actions
Physical interface (PIF) objects represent each of the four ports on a G4SA through which LAN
