addressable controller (SAC), which contains one Ethernet physical interface (PIF), resulting in one
Ethernet port on each GESA CRU.
Location in OSM Tree: System > Group > Module > GESA
Slot Location: GESA CRUs can be located in slots 53 and 54 in PMF enclosures (service side) or in
slots 51, 52, 53, and 54 in IOMF or IOMF2 enclosures (service side).
Example: GESA $ZZLAN.GESA0 (1.1.53)
Attributes
GESA
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Physical
Power State
Whether the component is powered on. Values
Part Number
The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.
Track ID
A unique serial number that identifies the component. Track IDs are used for
tracking components.
Hardware Revision
A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.
Logical
Configured Type
The configuration type of this resource.
Values: CCSA, E4SA, FESA, G4SA, GESA, TRSA, Unknown
Device State
The state of the component as known to the operating system on the server.
Values
Actions
Abort
Terminates operation of the Gigabyte Ethernet ServerNet adapter (GESA) and the associated
Ethernet ServerNet addressable controller (SAC). When the Abort action finishes, the GESA and the
SAC are in the Stopped state.
Start
Starts the Gigabyte Ethernet ServerNet adapter (GESA) and the associated Ethernet ServerNet
addressable controller (SAC). The GESA and the SAC must be in the Stopped state before you
