OSM User's Guide (G06.27+)

Set Locator
Allows you to assign identification text, up to 64 characters, that is displayed by the IOAM Locator
attribute.
Synchronize FIR Files
Synchronizes the FRU information Record (FIR) files of the X and Y fabric processor switches.
Write LCD Line
Allows you to edit the text displayed by the IOAMs LCD. You can modify lines 9 through 15 with
this action.
IOAM Enclosure
Attributes
Actions
An enclosure that contains two I/O Adapter Modules.
Location in OSM Tree: System > Group > IOAM Enclosure
Example: IOAM Enclosure 13
Attributes
Logical
Rack Name
An arbitrary name assigned through the Set Rack Name and Offset action.
Rack Offset
A number assigned through the Set Rack Name and Offset action, intended to describe
the physical location of the enclosure within the rack.
Actions
Replace IOAM Enclosure or ServerNet Switch Board
Launches a guided procedure, which provides step-by-step instructions for replacing the entire
IOAM enclosure or an individual ServerNet switch board within the enclosure.
Set Rack Name and Offset
Allows you to assign a rack name and rack offset for the enclosure. Rack name and rack offset are
displayed in the LCD for each IOAM and also as attributes under the enclosure object. Rack name is
arbitrary and can be up to eight characters long. Rack offset allows you to specify the physical
location within the rack. These ASCII characters cannot be used: =, +, &, or %.
