Location in OSM Tree: System > Group > Module > PMF2 > MIOE
Slot Location: Located on PMF CRUs in slots 50 and 55 of processor enclosures in Group 1
Example: MIOE $ZZLAN.MIOE0
Attributes
MIOE
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Logical
Configured Type
The configuration type of this resource.
Values: CCSA, E4SA, FESA, G4SA, GESA, TRSA, Unknown
Device State
The state of the component as known to the operating system on the server.
Values
Actions
Abort
Terminates operation of the MIOE. When the Abort action finishes, it is in the Stopped state.
Start
Starts the MIOE. It must be in the Stopped state before you perform this action. When the Start
action completes, the MIOE is in the Started state.
Stop
Rather than automatically stopping the MIOE (as the Abort action does), this action first warns you if
the MIOE is currently in use (and stops it only after you confirm).
MIOE PIF
Attributes
Actions
The physical interface through which the MIOE is logically connected to the system.
Location in OSM Tree: System > Group > Module > PMF2 > MIOE >MIOE SAC > MIOE PIF
Example: MIOE PIF $ZZLAN.MIOE0.0.A
