Performs basic tests on the CRU. You can perform this action when the CRU is online.
PMF2 (Processor Multifunction 2)
Attributes
Actions
Each processor multifunction 2 (PMF2) CRU in a NonStop server contains these components:
A processor and memory board (PMB), which contains a processor●
A service processor (SP)●
Two internal SCSI controllers●
One external SSAC●
And for PMF2s in Group 1 only, an MIOE (Ethernet controller) to provide connectivity
between the service processor and the dedicated service LAN (for OSM).
●
Slot Location: PMF2 CRUs are located in slots 50 and 55 of a processor enclosure (service side).
Example: PMF2 (1.2.50)
Attributes
PMF2
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Physical
Power State
Whether the component is powered on. Values
Part Number
The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.
Track ID
A unique serial number that identifies the component. Track IDs are used for
tracking components.
Hardware Revision
A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.
Logical
Fan Voltage The current voltage of the Fan CRU.
Main Rail Voltage
The voltage of the Main Rail, which supplies power to the CRU
from its own power supply
