Slot Location: SCSI controllers are located on PMF CRUs in slots 50 and 55 of processor
enclosures and on IOMF CRUs in slots 50 and 55 of I/O enclosures.
Example: SCSI Controller (1.1.55.1)
Attributes
SCSI Controller
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Logical
SCSI ID
The ID to which the device answers on the SCSI bus:
4 or 5: Tape devices
6 or 7: Controllers
8 and 9: SCSI extenders/FC converters
The remaining IDs are for the device on the SCSI bus.
SCSI Bus Number
The bus to which the device is attached:
Bus 1 or 2: Internal device
Bus 3: External device
Actions
Responsive Test
Verifies that the component is installed and responding.
SEB
Attributes
Actions
The ServerNet expansion boards (SEBs) and cables allow processors in one enclosure to
communicate with processors in another enclosure. Each SEB CRU provides either the ServerNet X
fabric or the ServerNet Y fabric for a group.
Location in OSM Tree: System > Group > Module > SEB
Slot Location: SEBs must be located in slots 51 and 52 of processor enclosures (service side).
Example: SEB (1.1.52)
