OSM User's Guide (G06.27+)

ME Firmware
Version The version of the ME firmware running on the switch board.
Default File Name The name of the file to be used for a firmware update.
Default File Version The version of the firmware to be used for a firmware update .
Compare State
The differences, if any, between the current and default firmware versions.
Values
Actions
Dump Memory
Dumps a snapshot of the ServerNet Switch Board's logic board memory, created by the Enable
Memory Snapshot action, to a file in $SYSTEM.ZSERVICE.
You can view the filename in the Action Detail dialog box for this action.
The filename convention is ZMmmmssn, whereby:
mmm = module number
ss = slot number
n = version number (incremented for subsequent versions of the same ZMmmmss snapshot files)
Example: ZM100023: snapshot file taken of ServerNet Switch Board in module 100, group 02,
version number 3.
Enable Memory Snapshot
Creates a snapshot of the ServerNet Switch Board's logic board memory. Perform Dump Memory to
dump this snapshot to a file in $SYSTEM.ZSERVICE.
Hard Reset
Resets the ServerNet Switch Board hardware and the routing tables.
ME FPGA Update
Allows you to update the FPGA code file for the Maintenance Entity (ME) of the ServerNet Switch
Board.
ME Firmware Update
Allows you to update the firmware file for the Maintenance Entity (ME) of the ServerNet Switch
Board.
Power Cycle
