Initialization State
The status of the storage ASIC in the CRU.
Values: Initialized, Not Initialized, Unknown
Actions
Replace
Launches the Replace SNDA guided procedure, which provides step-by-step instructions for
replacing the ServerNet/DA CRU.
Storage ASIC Initialization Test
Prompts the storage subsystem manager process ($ZZSTO) to initialize the storage ASIC in the
CRU. If initialization fails, an alarm is generated.
This action is triggered automatically when a new CRU is inserted while OSM is running or when an
SCF STATUS ADAPTER command is issued. If a CRU is inserted while OSM is not running,
perform this action after logging on to the OSM Service Connection.
Test Verify
Performs basic tests on the CRU. You can perform this action when the CRU is online.
SSAC (SCSI SAC)
Attributes
Actions
The SCSI SAC (ServerNet addressable controller) is a SCSI plug-in card mounted on these devices:
Processor multifunction 2 (PMF2) CRU (external SCSI controller, SAC 3)●
I/O multifunction (IOMF2) 2 CRU (external SCSI controller, SAC 3)●
ServerNet/DA CRU (There can be up to four SCSI SACs on each ServerNet/DA CRU.)●
SCSI SACs are used for connecting external SCSI devices such as tape drives.
Location in OSM Tree: System > Group > Module > IOMF2 > SSAC
Example: SSAC (1.1.50.3)
Attributes
SSAC
