that connects to a system through dual Ethernet ports. It supports both synchronous and
asynchronous protocols over a variety of electrical interfaces. The SWAN CRU object displayed by
OSM can be either a SWAN or SWAN 2 CRU. To distinguish between them, look at their
subcomponents.
Each SWAN CRU contains up to three CLIPs, each of which contains two SWAN Paths and two
WAN Lines, giving each SWAN CRU as many as six WAN ports.
Each SWAN 2 CRU contains these subcomponents:
Up to six SWAN 2 CLIPs, each of which contains two SWAN Paths and two WAN Lines,
giving each SWAN 2 CRU as many as twelve WAN ports
●
Two LAN Logic Board CRUs●
Two Fan CRUs●
Two Power Supply CRUs●
One Battery●
Location in OSM Tree: System > SWAN Collection > SWAN [or SWAN2]
Slot Location: WAN CRUs are external to the enclosures.
Example: SWAN2 $ZZWAN.#SWAN2
Attributes
SWAN $ZZWAN
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Physical
Part Number
The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.
Track ID
A unique serial number that identifies the component. Track IDs are used for
tracking components.
Hardware Revision
A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.
Logical
Adapter Type
The type of SWAN concentrator.
Values: Synchronous or Firmware Controlled
