Runs the power-on self-test for the CLIP. The FAULT LED on the CLIP flashes during the test. If
the test passes, the FAULT LED goes off. If the test fails, the FAULT LED remains on continuously.
SWAN Collection
Attributes
Actions
When one or more SWAN concentrator CRUs are connected to a system, a SWAN Collection object
appears in both the tree pane and the overview pane of the OSM Service Connection. In both panes,
this object displays an alarm or yellow icon if alarms or degraded conditions exist on any of the
individual SWAN CRUs contained within. You can expand the SWAN Collection icon in the tree
pane (but not in the overview pane) to select and monitor individual SWAN CRUs and their
subcomponents.
Location in OSM Tree: Under System
Example: SWAN Collection
Attributes
None.
Actions
None.
SWAN FAN
Attributes
Actions
Each SWAN 2 CRU has two customer-replaceable fan subcomponents.
Location in OSM Tree: System > SWAN Collection > SWAN > Fan
Example: Fan $ZZWAN.#SWAN2.FAN1
Attributes
Fan $ZZWAN
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Logical
