OSM User's Guide (G06.27+)

Device State
The state of the component as known to the operating system on the server. Values
Actions
None.
SWAN LAN Logic Board (LANLB)
Attributes
Actions
Each SWAN 2 CRU has two customer-replaceable LAN logic board subcomponents.
Location in OSM Tree: System > SWAN Collection > SWAN > LANLB
Example: LAN LB $ZZWAN.#SWAN2.LAN1
Attributes
LAN LB $ZZWAN
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Physical
Part Number
The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.
Track ID
A unique serial number that identifies the component. Track IDs are used for
tracking components.
Hardware Revision
A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.
Logical
Link State
The status of the Ethernet link.
Values: Up, Down, Not Available
Duplex Mode
The duplex mode of the connection between the logic board and the router.
Values: Half Duplex, Full Duplex, Not Available
Maximum Speed
The maximum speed of the connection between the logic board and the router.
Values: 10Mbps, 100Mbps, Not Available
Board State
The operational status of the SWAN 2 LAN logic board CRU.
Values: OK, Fault, Not Available
