Actions
None.
SWAN Line
Attributes
Actions
A subcomponent of SWAN CLIPs and SWAN 2 CLIPs. Every CLIP has two lines, which represent
the ports on the CLIP.
Location in OSM Tree: System > SWAN Collection > SWAN > CLIP > Line
Example: Line $ZZWAN.#SWAN2.1.0
Attributes
Line $ZZWAN
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Logical
DLC Task Name
The name of the data link control (DLC) task associated with the line.
Format: adapter name.clip number.DLC line number
Example: $ZZWAN.#D08XE5.1.DLC0
DLC Task State
The state of the data link control (DLC) task associated with the line as known to
the operating system.
Values: Started, Stopped, Unknown
Device Name
The name of the WAN device associated with the line.
Example: $TP6S1
If no device is configured, "FREE" is shown.
Actions
External Loopback Test
Performs the external loopback firmware diagnostic test.
Start DLC Task
