Starts the data link control (DLC) task associated with the SWAN Line. When the Start action
completes, the task is in the Started State.
Stop DLC Task
Stops the data link control (DLC) task associated with the SWAN Line. When the Start action
completes, the task is in the Stopped State. Device objects already using the task are not affected by
this action, but subsequent attempts to download tasks will fail.
SWAN Path
Attributes
Actions
A subcomponent of SWAN CLIPs and SWAN 2 CLIPs. Every CLIP has two paths, path A and path
B. These paths represent the two Ethernet interfaces on the SWAN concentrator.
Location in OSM Tree: System > SWAN Collection > SWAN > CLIP > Path
Example: PATH $ZZWAN.#SWAN2.1.B
Attributes
PATH $ZZWAN
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Logical
MAC Address The media access control (MAC) address of the SWAN Path.
IP Address The IP address configured for the SWAN Path.
Path State
The state of the SWAN Path as known to the operating system.
Values: Started, Stopped
Actions
Start
Starts the SWAN Path. When the Start action completes, the SWAN Path is in the Started state.
Stop
Terminates operation of the SWAN Path. When the Stop action completes, the SWAN Path is in the
Stopped state.
