OSM User's Guide (G06.27+)

Configure ServerNet Node
Procedure has been streamlined and renamed. It is now launched
by the Add Node to ServerNet Cluster action of the System
resource.
For more information, see Guided Procedures.
For more information about using software such as SCF to manage one of the star topologies,
see the ServerNet Cluster 6770 Supplement.
Router Connections in a Layered Topology
Router Connections for Switch Node Ports
Router Connections for Ports Connecting to Other Switches
Router Connections for Router Interconnect PICs
Router Connections for Switch Node Ports
External Slot Port Internal Router Port
6 1 1 0
2 1 1
7 1 2 0
2 2 1
8 1 3 0
2 3 1
9 1 4 0
2 4 1
Router Connections for Ports Connecting to Other Switches
External Slot Port Internal Router Port
Zone 2 1 5 6
2 5 7
3 1 5 8
2 5 5
Layer 11 1 3 7
2 4 7
3 1 7
4 2 7
12 1 2 8
