OSM User's Guide (G06.27+)

A hardware component that provides connectivity for multiple nodes of a second-generation
ServerNet cluster using the layered topology. As part of the layered topology, the 6780 switch
module comprises one cluster switch layer within a cluster switch group. The 6780 switch
connects to the nodes through fiber-optic cables that connect to modular ServerNet expansion
boards (MSEBs) on each node.
The subcomponents of the 6780 switch module are the Switch Logic Board, Switch PICs,
Switch Ports, Switch Power Supply, and Switch Fan.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module
Example: witch Module $ZZSMN.Y21 (1021.1)
[The 6780 switch module on the Y fabric of zone 2, occupying layer 1]
Attributes
Switch Module
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Midplane Physical
Primary AC Power State Whether the primary power source is On or Off.
Backup AC Power State Whether the backup power source is On or Off.
Part Number The part number of the switch module midplane.
Presence
Whether the switch module is installed and responding.
Values: Present, Absent, and Unknown
Track ID The track ID of the switch module midplane.
Hardware Revision The hardware revision of the switch module midplane.
Logical
Globally Unique ID
A unique, read-only number stored in nonvolatile memory
(SEEPROM) on a cluster switch. The Globally Unique ID
can be used programmatically to identify the switch.
Current Numeric Selector
Setting
The current value of the 4-digit numeric selector setting.
Example: 9621
Locator
User-assigned text, that can be used to help identify the
module. The text is assigned by using the Set Locator action.
Example: Switch Group On Right in 1206
