OSM User's Guide (G06.27+)

Actions
Node Connectivity ServerNet Path Test
Checks the local node's connection to the ServerNet cluster by testing the external fabric (X or
Y) between the MSEB on the local node and the cluster switch on the fabric.
Rediscover
Causes OSM to refresh and reanalyze the object and all subcomponents. Refresh refers to OSM
updating the attribute values displayed in the OSM Service Connection interface. Reanalyze
refers to the running of OSM incident analysis, which checks EMS event messages and creates
alarms in OSM if certain conditions exist.
Remote 6770 Switch
Attributes
Actions
The nodes connected directly to one switch see the other switches as remote switches. Although
local and remote switches are the same from a hardware standpoint, less information and no
actions are available for the remote switch. To perform actions or get additional information on
a remote switch, establish a service connection from one of the nodes that connects directly to
that switch.
Location in OSM tree: External ServerNet Fabric > Remote Switch
The last part of the switch name indicates the fabric and position of the switch in the topology.
Example: Remote Switch $ZZSMN.X2
Attributes
Remote Switch
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Physical
