OSM User's Guide (G06.27+)

Configuration Tag

A parameter used by SCF and the guided procedures that allows

SANMAN to select an appropriate switch configuration block (SCB)

from the M6770CL switch configuration library. The selected SCB is

subsequently loaded on the specified switch. The configuration tag

determines the position of the cluster switch in the topology and the

ServerNet node numbers supported by the cluster switch. Values

Example: Max 24 nodes, nodes 1-8

GUID

A unique, read-only number stored in nonvolatile memory

(SEEPROM) on a ServerNet II switch. The Globally Unique ID can be

used programmatically to identify the switch.

Fabric Setting

Whether the switch is configured for operation on the X fabric or the Y

fabric.

Values: X, Y, or Clear

Presence

Verification that the switch is installed and responding.

Values: Present, Absent, Unknown

Configuration Version

The version of the configuration file currently loaded on the switch.

Example: 1_5

Firmware Version

The version of the firmware currently loaded on the switch.

Example: 3_0_23

Actions

None.

ServerNet Cluster

Attributes

Actions

A ServerNet cluster is a collection of NonStop servers connected together that function as a

single processing unit. Servers within a ServerNet cluster pass information to each other using

the ServerNet protocol.

Location in OSM tree: Located at the top level.
