Remote Line LDEV State
The state of the Expand-over-ServerNet line configured from the
remote node to the local node.
Values: Up, Down, Unknown
Actions
Generate ServerNet Statistics
Generates an event containing the ServerNet statistics from the local node to the remote node.
ServerNet II Switch
Attributes
Actions
The component of the 6770 switch module that provides routing for the cluster over an external
ServerNet fabric. The ServerNet II switch connects to the nodes through fiber-optic cables that
connect to plug-in cards (PICs) located on modular ServerNet expansion boards (MSEBs) on
each node.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch
Example: Switch $ZZSMN.Y1
Attributes
Switch
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Logical
GUID
A unique, read-only number stored in nonvolatile memory (SEEPROM) on a
ServerNet II switch. The Globally Unique ID can be used programmatically to
identify the switch.
Fabric Setting
Whether a switch is configured for operation on the X fabric or the Y fabric.
Values: X, Y, or Clear
Firmware
