OSM User's Guide (G06.27+)

Version
The version of the firmware currently loaded on the switch. The attribute
value includes the VPROC string with the firmware version in parentheses.
You can also obtain this value from SCF.
Example: T0569G06^06MAY02^FMW^AAF (3_0_82)
Default File Name The name of the file to be used for a firmware update.
Default File
Version
The version of the firmware to be used for a firmware update.
Compare State
The differences, if any, between the current and default firmware versions.
Values
Configuration
Configuration Tag
A parameter used by SCF and the guided procedures that allows
SANMAN to select an appropriate switch configuration block (SCB)
from the M6770CL switch configuration library. The selected SCB is
subsequently loaded on the specified switch. The configuration tag
determines the position of the cluster switch in the topology and the
ServerNet node numbers supported by the cluster switch. Values
Example: Max 24 nodes, nodes 17-24
Version
The version of the configuration currently loaded on the switch. The
attribute value includes the VPROC string with the configuration version
in parentheses. You can also obtain this value from SCF.
Example: T0569G06^02Jul01^CL4^AAE (2_5)
Default File Name The full path name of the default configuration file M6770CL.
Position ID
A number that indicates the position that the switch occupies in a
network topology. The Position ID is a component of the switch name.
For example, the switch name X3 indicates that the switch serves the
external ServerNet X fabric and occupies position 3 in the topology.
Default File Version The version of firmware in the default configuration file M6770CL.
Compare State
The differences, if any, between the current and default configuration
versions. Values
Actions
Blink LED Off
Turns off the blinking of the LED.
SCF Equivalent: SCF ALTER SWITCH $ZZSMN, NEAREST { X | Y}, BLINK NONE
Blink LED On
