Hard resets the switch logic board.
SCF Equivalent: RESET SWITCH, HARD
Replace
Invokes the Replace Switch Component guided procedure that helps to replace the switch logic
board.
Soft Reset
Soft resets the switch logic board.
SCF Equivalent: RESET SWITCH, SOFT
Switch PIC
Attributes
Actions
A card in the 6780 switch that plugs into the switch logic board. Most switch PICs (except for
maintenance PICs and router interconnect PICs) are populated with transceivers that enable
connections to the different nodes, layers, and zones of the cluster.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch
PIC
Example: Switch PIC $ZZSMN.Y11.13 (1011.1.13)
See also Router Connections for Router Interconnect PICs.
Attributes
Switch PIC
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Physical
Type
The type of PIC.
Values: Single-mode fiber-optic, Multimode fiber-optic, Router
Interconnect, Maintenance
Part Number The part number of the switch PIC.
