Actions
Node Responsive Test
Tests the connectivity on the external ServerNet fabric through this port.
Switch Node Port
Attributes
Actions
On the 6780 switch, an external transceiver port that connects to a ServerNet node.These ports
reside only on switch PICs in slots 6 through 9.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch
PIC > Switch Port
Example: Switch Port (1010.1.6.1)
See also Router Connections for Switch Node Ports.
Attributes
Switch Node Port
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Transceiver Physical
Type
The type of transceiver.
Example: 9/125 Micron SMF
Part Number The vendor part number of the transceiver.
Serial Number The vendor serial number of the transceiver.
Hardware Revision The vendor hardware revision of the transceiver.
Logical
