Node Number The ServerNet node number of the neighbor node.
Node Name The name of the neighbor node.
Actions
Node Responsive Test
Tests the connectivity on the external ServerNet fabric from the local node to the remote node
connected via this port.
Switch-to-Switch PIC
Attributes
Actions
A plug-in card (PIC) on the 6770 switch module that connects to another switch on the same
fabric. The last part of the name contains the port number where the PIC is located. Only the
PICs in ports 8 through 11 of the switch are used for switch-to-switch connections.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch
> Switch PIC
Example: Switch PIC $ZZSMN.Y3.10 (indicates the PIC in port 10 of switch Y3)
Attributes
Switch PIC
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Logical
