Connectivity Status
The state of connectivity between the switch and the node to which this
PIC connects.
Values:
Connected
Not Connected
Connected to Switch With Wrong Fabric
Connected to Node
Connected to Wrong Port
Connected to Different Switch
Connected to Switch With Wrong Configuration
Unknown
Presence
Whether the PIC is installed and responding.
Values: Present, Absent, Unknown
Neighbor Switch PIC
PIC Name
The neighbor switch and PIC to which this PIC is connected.
Example: Switch PIC $ZZSMN.X.1.8 (indicates that this PIC is connected to
switch X1, PIC 8)
Actions
None.
Switch Port
Attributes
Actions
An external transceiver port on a 6780 switch that connects to a 6780 switch in another zone or
layer. These ports reside only on switch PICs in slots 2 and 3 (for zone connections) and 11
through 13 (for layer connections).
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch
PIC > Switch Port
Example: Switch Port (1010.1.13.4)
See also Router Connections for Ports Connecting to Other Switches.
