Current Speed The speed of the port in bits per second.
Transceiver Device State
The initial state of the component at the time of discovery.
Values: OK, Fault
Transceiver Enabled State
Whether the transceiver is enabled.
Enabled: The component is operational.
Disabled: The component is present but not operational.
Neighbor Switch Port
Switch Port
The name of the port to which this port is connected.
Format: Port (Group.Module.Slot.Port)
where:
Group can be 1010, 1020, 1030, 1011, 1021 or 1031.
Module can be 1, 2, 3 or 4.
Slot can be 2, 3, 11, 12 or 13.
Port can be 1, 2, 3 or 4.
Actions
None.
UPS (6770 Switch Module)
Attributes
Actions
The uninterruptible power supply (UPS) is a component of a 6770 switch module that provides
two hours of power if both the primary and backup AC power sources fail.
Location in OSM tree:External ServerNet Fabric > Switch Group > Switch Module > UPS
Example:UPS $ZZSMN.X1
Attributes
UPS
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
