OSM User's Guide (G06.27+)

Asynchronous Transfer Mode (ATM) network through a logical connection known as an ATM line.
Each ATM CRU contains one ATM line.
Slot Location: ATM CRUs can be located in slots 53 and 54 in processor enclosures (service side)
or in slots 51, 52, 53, and 54 in IOMF or IOMF2 enclosures (service side).
Example: ATM3SA (12.1.53)
Attributes
ATM3SA
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Physical
Power State Indication of whether the component is powered On or Off.
Part Number
The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.
Track ID
A unique serial number that identifies the component. Track IDs are used for
tracking components.
Hardware Revision
A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.
Logical
Dump Filename The name of the file used to store dumps of the ATM CRU memory.
Physical Transmission Type
The type of transmission used by the ATM CRU. This might be either
a standard, such as SONET, or a line speed, such as 155 Mbps.
MAC Address The media access control (MAC) address of the ATM CRU.
Automatic Dump State
Indication of whether the ATM adapter software is automatically
dumped to the specified dump file if the software abends abnormally.
Enabled: The software is automatically copied.
Disabled: The software is not automatically copied.
Unknown:: The Automatic Dump state could not be read.
Media Type
The type of media or cable, such as single-mode fiber or coaxial cable,
supported by the ATM CRU.
