Disk (Fibre Channel)
Attributes
Actions
A fibre channel disk that resides in a disk drive enclosure.
Location in OSM Tree: System > Group > Daisy Chained Disk Drive Enclosure > Disk Drive
Enclosure > Disk
Example: Disk (111.211.1.3)
Attributes
Disk (Fibre Channel)
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK. Values
Physical
Port B Bypass State The state of the Port B Bypass (Enabled or Disabled).
Port A Bypass State The state of the Port A Bypass (Enabled or Disabled).
Part Number
The part number of the component that was assigned in manufacturing.
Use part numbers for identifying and ordering parts.
Serial Number
The serial number of the component assigned to it by the supplier of the
component.
Port A EMU Access State The state of the Port A access to the EMU (Up or Down).
Port A World Wide Name A unique, 64-bit number assigned to enclosure Port A.
World Wide Name A unique, 64-bit number assigned to hardware ports.
LED State
Indicates whether or not the disk drives (amber) fault LED is blinking.
Value: Blinking or Off
Port B EMU Access State The state of the Port B access to the EMU (Up or Down).
Device State
The state of the component as known to the operating system on the
server.
Port B World Wide Name A unique, 64-bit number assigned to enclosure Port B.
Logical
