Managing RDF
HP NonStop RDF System Management Manual—524388-003
5-10
TMF Audited Volume Crash
RDF State Transition Failure
Periods during which the RDF updaters (or RDF itself) are either starting or stopping
are known as RDF state transitions. In rare instances, when a primary CPU fails for
an RDF process during execution of a STOP RDF or STOP UPDATE command, not all
RDF processes complete the state transition properly.
To minimize the chance of encountering this kind of failure, avoid CPU reloads during
RDF state transitions. Furthermore, if a CPU failure does occur during a state
transition, carefully review the EMS event log for signs of incorrect behavior. If the
failure occurred while RDF or the updating facility was stopping, check the Process
Pair Directory (PPD) to ensure that the appropriate RDF processes all have stopped; if
they have not, you must stop them manually.
If a state transition failure occurs during execution of a STOP RDF command and the
operation appears to be stalled, manually stop all of the RDF processes by issuing the
following command on both the primary and backup system:
STATUS *, PROG RDF-software-loc.*, STOP
If a state transition failure occurs during execution of a STOP UPDATE command and
the operation appears to be stalled, manually stop all of the RDF updaters by issuing
the following command on the backup system:
STATUS *, PROG RDF-software-loc.RDFUPDO, STOP
TMF Audited Volume Crash
RDF can recover from a crash of a TMF audited volume on the primary or backup
system. If the volume is successfully recovered by volume recovery, then you do not
have to perform any special RDF procedures.
TMF Subsystem Crash on the Primary System
RDF can recover from a TMF crash on the primary system if the TMF volume recovery
operation is successful after the crash. For this recovery, proceed as follows:
1. Stop RDF on the primary system by entering the following command through
RDFCOM:
]STOP RDF
2. Restart TMF by entering the following command sequence through TMFCOM:
~DISABLE DATAVOLS *
~START TMF
Notice that these commands prevent any disk volumes on the local system from
being enabled for TMF operations before starting the subsystem.
Caution. Issuing this command in this situation is only safe, however, if this is the backup
system for a single RDF environment.
