Entering RDFCOM Commands
HP NonStop RDF System Management Manual—524388-003
8-97
Command Overview
The RTD value reported for each updater process is the difference between the “last
modified time” of the TMF master audit trail (MAT) and the timestamp in the most
recent image record seen by the particular updater.
The RTD value reflects, in the most general sense, the amount of time by which the
backup database is lagging behind the primary database. In the example shown under
STATUS RDF Command Output Display earlier in this command description, the
specified RTD time for the updater $RU03 is 0 minutes and 6 seconds, meaning that
the updater is running approximately 6 seconds behind the MAT.
On a finely tuned RDF backup node, the RTD for an updater can regularly lag 1 to 15
seconds behind TMF processing. However, this 15-second delay does not mean that
15 seconds are needed to catch up; that operation may take only a few seconds.
If RDFCOM cannot connect to a particular process, RDFCOM displays dots (...) in the
RTD Time, Sequence, and Rel Byte No fields, and an appropriate file-system error
number in the Error field.
Pri
The fourth column specifies the priority at which each process is running.
Volume and Seqnce
The fifth and sixth columns together specify a file associated with each process, as
follows:
•
The monitor entry reflects the name of the MAT file to which TMF is writing
($AUDIT.ZTMFAT.AA000056 in this example).
•
Each extractor entry reflects the name of the TMF audit trail file from which it is
reading ($AUDIT.ZTMFAT.AA000056 for the master extractor and
$DATA17.ZTMFAT.BB000004 for the auxiliary extractor in this example).
•
The receiver entries reflect the names of the primary image trail files to which each
receiver is writing ($DATA01.RDF04.AA000044 and $DATA02.RDF04.AA000003
in this example).
•
The imagetrail entries reflect the names of the secondary image trail files to which
each receiver is writing ($DATA03.RDF04.AA000022 and
$DATA04.RDF04.AA000003 in this example).
•
Each updater entry reflects the name of the secondary image file from which it is
reading ($DATA03.RDF04.AA000020 for $RU01, $DATA04.RDF04.AA000003 for
$RU02, and $DATA05.RDF04.AA000003 for $RU03 in this example).
If RDFCOM cannot connect to a particular process, RDFCOM displays dots (...) in the
RTD Time, Sequence, and Rel Byte No fields, and an appropriate file-system error
number in the Error field.
