Zero Lost Transactions (ZLT)
HP NonStop RDF System Management Manual—524388-003
16-3
How It Works
Figure 16-2 shows the configuration where a single system serves as both the standby
and backup systems, and the remote mirror is located at an intermediate site.
Figure 16-2. ZLT Configuration With a Single Standby/Backup System, and the
Remote Mirror Located at an Intermediate Site
System A
(RDF primary)
System B
(RDF backup
and standby)
X fabric
Y fabric
RDF traffic
(Expand lines)
X fabric
Y fabric
Audit-Trail
Disk
Audit-Trail
Disk
Limited by
disk technology
Limited by
disk technology
