Using ASAP
HP NonStop RDF System Management Manual—524388-003
E-4
RDF Metrics Reported by ASAP
RDF Metrics Reported by ASAP
For each RDF entity, the RDF SGP passes the information shown in Table E-1 back to
ASAP.
Table E-1. RDF Metrics Reported by ASAP
Information Passed to ASAP
Monitor
Extractor
Receiver
Imagetrail
Purger
RDFNET
Updater
Name XXXXXX
1
X
Operational Status:
“Running” XXXXXX
1
X
“Error” ——X ———X
“Stopped” XXXXXX
1
X
“Aborted” XXXXXX
1
X
“Updt off” ——————X
“TKOV complete” XXXXXX
1
X
“TKOV part complete” XXXXXX
1
X
“TKOV active” XXXXXX
1
X
Error XXXXXX
1
X
Pin XXX—XX
1
X
Primary Volume ——————X
Backup Volume ——————X
Volume XXX
2
X ——X
TMF Auxiliary Audit Index — X X X — — X
File Sequence Number X X X ———X
Relative Byte Address —X ————X
RTD Time X X X ———X
Primary CPU XXX—XX
1
X
Backup CPU XXX—XX
1
X
Priority XXX—XX
1
X
1
only in an RDF Network environment
2
only reported by the master receiver where the master imagetrail (MIT) volume is reported
